China Factory EV Charger 32A 230V 7.2kw Type 2 to Type 2 EV Charging Cable

Short Description:

China Factory EV Charger 32A 230V 7.2kw Type 2 to Type 2 EV Charging Cable,Shell Material: Thermo Plastic ( Insulator inflammability UL94 VO),Contact Pin: Copper alloy, silver or nickel plating,Sealing gasket: rubber or silicon rubber.Our EV charging cables are manufactured in a rigorous process for reliable quality, comply with EU RoHs and are CE and TUV certified. The material is TPU, which controls the outer diameter and keeps the cable soft when bent, and is also resistant to abrasion, oil, ozone, ageing, radiation and low temperatures, ensuring that the product can be used in a variety of environments and has excellent universality.

Rated Current: 16A ,32Amp (Adjustable)

Operating Voltage: 250V~480V AC

Insulation Resisitance: >1000MΩ

Therminal Temperature rise: <50K

Withstand Voltage: 2000V

Send email to us

Product Detail

Product Tags

China Factory EV Charger 32A 230V 7.2kw Type 2 to Type 2 EV Charging Cable

Materials

Shell Material: Thermo Plastic ( Insulator inflammability UL94 VO)
Contact Pin: Copper alloy, silver or nickel plating
Sealing gasket: rubber or silicon rubber

TPU insulation,TPU Sheath EV Charging Cable for EV Plug & EV Socket ,32A 240V 62196

Product Model	HENGYI-EVFM-16A-SP HENGYI-EVFM-32A-SP			HENGYI-EVFM-16A-TP HENGYI-EVFM-32A-TP
Rated Current	16A / 32A Single Phase			16A / 32A Three Phase
Operation Voltage	AC 250V			AC 480V
Insulation Resistance	＞1000MΩ ( DC 500V )
Withstand Voltage	2000V
Pin Material	Copper Alloy, Silver Plating
Shell Material	Thermoplastic,Flame Retardant Grade UL94 V-0
Mechanical Life	No-Load Plug In / Pull Out ＞10000 Times
Contact Resistance	0.5mΩ Max
Temperature Rise	＜50K
Operating Temperature	-30°C~+50°C
Impact Insertion Force	>300N
Waterproof Degree	IP55
Cable Protection	Reliability of materials,antiflaming,pressure-resistant, abrasion resistance,impact resistance and high oil
Certification	TUV,CE Approved
Model	Current	Phase	Cable Specification	Color	Cable Length
HENGYI-EVFM-16A-SP	16Amp	1Phase	3 X 2.5mm² + 1 X 0.5mm²	Black Orange Green	(5M ,10M) The length of cable can be customized
HENGYI-EVFM-32A-SP	32Amp		3 X 6.0mm²+1 X 0.5mm²
HENGYI-EVFM-16A-TP	16Amp	3Phase	5 X 2.5mm² + 1 X 0.5mm²
HENGYI-EVFM-32A-TP	32Amp		5 X 6.0mm²+1 X 0.5mm²
